Updated to KR30105L4
| Installation | suspended for indoor applications |
|---|---|
| Power consumption | 21W |
| Power supply | 230Vac |
| Lumen output at source | 1870 lm (3000K) |
| Delivered lumen output | 1289 lm (3000K, 38°) |
| Datasheet | Copied |
| Mounting | surface mounted (ceiling) with ceiling rose |
|---|---|
| Number and type of LED | 1 multichip power LED, 3-step MacAdam, 50 000h L80 B10 (Ta 25°C) |
| LED colour | 3000K |
| Optics | 65° |
| CRI Colour Rendering Index | 80 |
| Body material | body in anticorodal aluminium, ceiling rose in steel |
| Screen material | screen in plexiglass |
| Finishes | light ivory |
| Power supply unit | built-in power supply unit |
| Power cables | includes 2.50 m PVC cable, FROR 2x0.75 Ø5.4 mm |
| Ingress protection | IP40 |
| Notes | DALI and 0/1-10V versions available on request, Casambi-compatible version, controllable with the Casambi app, available on request |
| Design by | Cibicworkshop |
| Status | Available |
Accessories for product code KR30105L4
No accessories
Power supply units for product code KR30105L4
No power supply units
Control gear for product code KR30105L4
No controllers
No control inputs
