This product can be customized, thanks to our flexible in-house production. We suggest some of the possible customized versions on the right, but if you have any different requirements, we can review them together.
Updated to EA1010FDBN
| Installation | wall mounted for indoor applications |
|---|---|
| Power consumption | 7W |
| Power supply | 230Vac |
| Lumen output at source | 954 lm (3000K) |
| Delivered lumen output | 493 lm (3000K) |
| Datasheet | Copied |
| Mounting | surface mounted (wall) |
|---|---|
| Number and type of LED | 18 mid-power LEDs, 3-step MacAdam, 50 000h L80 B10 (Ta 25°C) |
| LED colour | 2700K |
| Optics | diffuse |
| CRI Colour Rendering Index | 80 |
| Body material | body in anticorodal aluminium |
| Screen material | screen in serigraphed extra-clear microprismatic glass |
| Finishes | white |
| Power supply unit | built-in power supply unit |
| Ingress protection | IP40 |
| Impact resistance | IK08 |
| Notes | Casambi-compatible version, controllable with the Casambi app, available on request |
| Status | Available |
Accessories for product code EA1010FDBN
WD0601BSpacer - white |
Power supply units for product code EA1010FDBN
No power supply units
Control gear for product code EA1010FDBN
No controllers
