Bright 2.4
Recessed for outdoor applications
recessed for outdoor applications - 5W/7W 24Vdc; RGB: max 5W max 500mA - fixed optics - ø85 mm
Recessed for outdoor applications
recessed for outdoor applications - 5W/7W 24Vdc; RGB: max 5W max 500mA - fixed optics - ø85 mm
This product can be customized, thanks to our flexible in-house production. We suggest some of the possible customized versions on the right, but if you have any different requirements, we can review them together.
Updated to CB240115JAI
Installation | recessed for outdoor applications (not suitable for use in immersion in swimming pools or fountains) |
---|---|
Power consumption | 7W |
Power supply | 24Vdc |
Lumen output at source | 608 lm (3000K, 7W, CRI >90) |
Delivered lumen output | 374 lm (3000K, 34°, 7W, CRI >90) |
Datasheet | Copied |
Mounting | recessed (ceiling, wall, floor) |
---|---|
Number and type of LED | 1 high-intensity power LED, 3-step MacAdam, 50 000h L90 B10 (Ta 25°C) |
LED colour | 3000K |
Optics | 47° |
CRI Colour Rendering Index | >90 |
Body material | body in black-anodized anticorodal aluminium, trim in AISI 316L stainless steel |
Screen material | screen in transparent, tempered extra-clear glass |
Finishes | stainless steel |
Body | black anodized aluminium |
Power supply unit | power supply unit not included |
Power cables | includes 1.5 m neoprene cable H05RN-F 2x0.75/0.75 Ø6.3 mm |
Ingress protection | IP65, IP68, IP69 |
Impact resistance | IK10 |
Notes | version with 5° optics (with white LED colour and 3,5W power) available on request; version with 9W power (with white LED colour) available on request |
Status | Available |
Accessories for product code CB240115JAI
![]() WC0100Outer casing |
![]() WC0103Outer casing |
![]() WC0150Outer casing |
![]() WG0100Retaining spring clip Ø70mm |
Power supply units for product code CB240115JAI
Control gear for product code CB240115JAI
![]() ADV576DALIN1Low-voltage dimmerorder in addition to PSU
|
![]() ARVUNID2-01Universal sequencer - Low-voltage 4-channel controller with constant-voltage outputorder in addition to PSU
|
||||||||||||||||
![]() EC0CEN12445A20Low-voltage 4-channel controller with constant-voltage output for CASAMBIWhite, dynamic white, RGB, RGBW, RGB+W
|
![]() EC0CEN1244DA20Low-voltage dimmer for CASAMBIorder in addition to PSU
|
![]() AE01350T1Emergency module integrated
|
![]() EC0TIM12840020Timer for CASAMBI
|
||||||||||||||||||||
![]() ECPNL2301DM20Touch-screen deviceRequired outer casing not included
|
![]() TLC08Remote control for TLR02-01, TLR04M-350-500 and TLR04M-350-700 controllers
|
||||||||||||||||||||
![]() TLC09Remote control for TLR02-01, TLR04M-350-500 and TLR04M-350-700 controllers
|
![]() TLC151-channel remote control for TLR07
|
||||||||||||||||||||
![]() TLC162-channel remote control for TLR07
|
![]() TLC174-channel remote control for TLR07
|
||||||||||||||||||||
![]() TLR072-channel receiver for TLC15, TLC16, TLC17 remote control(1/2 NO push buttons)
|
![]() TOUCH02L1Single-zone touch-screen deviceRequired outer casing not included WC0302
|
||||||||||||||||||||
![]() TOUCH03L14-zone touch-screen device with memoryRequired outer casing not included WC0302
|
