Zab Track 1.1

Projectors for indoor applications

projector for indoor applications - 29W 230Vac - 1 COB LED Citizen, CRI 94 - with optics - Ø89x93 mm

Generate code

Customize this product

This product can be customized, thanks to our flexible in-house production. We suggest some of the possible customized versions on the right, but if you have any different requirements, we can review them together.

Possible customizations:

Casambi-compatible version, controllable with the Casambi app

Technical data

Print technical data

kg 0,90
IP40

Installation	projector for indoor applications
Power consumption	29W
Power supply	230Vac
Lumen output at source	2645 lm (3000K)
Delivered lumen output	1750 lm (3000K, 29°)
Datasheet	Zab Track 1.1 projector for indoor applications; on horizontal track; Power consumption: 29W; Power supply: 230Vac; Lumen output at source: 2645 lm (3000K); Delivered lumen output: 1750 lm (3000K, 29°); 1 COB LED Citizen (3 MacAdam steps), 3-step MacAdam, 50 000h L90 B10 (Ta 25°C); LED colour: 2700K, 3000K, 4000K; Optics: 14°, 29°: optical system consisting of a high-efficiency TIR lens; CRI Colour Rendering Index: 94; Body material: body and screw ring made of extruded anodized aluminium, produced entirely on a CNC lathe; Finishes: body and ring anodized glossy black (RAL 9005), body and ring painted white (RAL 9003); RAL finish on request; built-in power supply unit; Ingress protection: IP40; Operating temperature: 0°C — +45°C; Photobiological safety: photobiological safety: risk group 1 according to EN 62471:2006; Appliance class: class I; Weight: 900 g; Dimensions: Ø89x93 mm; Energy efficiency class: F (light source) in accordance with EU 2019/2015; Accessories: BE0017001 Suspension kit with 2 m cable and clutch adjustment, BE0020011 Lighting track 3-CCT aluminium 1000 mm - white, BE0020021 Lighting track 3-CCT aluminium 2000 mm - white, BE0020031 Lighting track 3-CCT aluminium 3000 mm - white, BE0021001 Supply connector earth conductor on left - white, BE0021011 Supply connector earth conductor on right - white, BE0021101 Concealed coupling with wiring - white, BE0021201 End cap - white, BE0021301 L-shaped coupling ground external - white, BE0021311 L-shaped coupling ground internal - white, BE0021401 Flexible coupling - white, BE0022001 Cover - length 1000 mm - white, BE0030011 Lighting track 3-CCT aluminium 1000 mm - black, BE0030021 Lighting track 3-CCT aluminium 2000 mm - black, BE0030031 Lighting track 3-CCT aluminium 3000 mm - black, BE0031001 Supply connector earth conductor on left - black, BE0031011 Supply connector earth conductor on right - black, BE0031101 Concealed coupling with wiring - black, BE0031201 End cap - black, BE0031301 L-shaped coupling ground external - black, BE0031311 L-shaped coupling ground internal - black, BE0031401 Flexible coupling - black, BE0032001 Cover - length 1000 mm - black, BE0036101 3-phase recessed monopoint - black, BE0036111 3-phase ceiling monopoint - black, WB0401B Standard snoot - white, WB0401N Standard snoot - black, WB0402B Asymmetrical snoot - white, WB0402N Asymmetrical snoot - black, WB0403N Barn doors - black, WH0710 Honeycomb louvre ; tested and approved via E.O.L. (End Of Line) test with functioning test and check of electrical power consumptionZab Track 1.1 projector for indoor applications on horizontal track Power consumption: 29W Power supply: 230Vac Lumen output at source: 2645 lm (3000K) Delivered lumen output: 1750 lm (3000K, 29°) 1 COB LED Citizen (3 MacAdam steps), 3-step MacAdam, 50 000h L90 B10 (Ta 25°C) LED colour: 2700K, 3000K, 4000K Optics: 14°, 29°: optical system consisting of a high-efficiency TIR lens CRI Colour Rendering Index: 94 Body material: body and screw ring made of extruded anodized aluminium, produced entirely on a CNC lathe Finishes: body and ring anodized glossy black (RAL 9005), body and ring painted white (RAL 9003) RAL finish on request built-in power supply unit Ingress protection: IP40 Operating temperature: 0°C — +45°C Photobiological safety: photobiological safety: risk group 1 according to EN 62471:2006 Appliance class: class I Weight: 900 g Dimensions: Ø89x93 mm Energy efficiency class: F (light source) in accordance with EU 2019/2015 Accessories: BE0017001 Suspension kit with 2 m cable and clutch adjustment, BE0020011 Lighting track 3-CCT aluminium 1000 mm - white, BE0020021 Lighting track 3-CCT aluminium 2000 mm - white, BE0020031 Lighting track 3-CCT aluminium 3000 mm - white, BE0021001 Supply connector earth conductor on left - white, BE0021011 Supply connector earth conductor on right - white, BE0021101 Concealed coupling with wiring - white, BE0021201 End cap - white, BE0021301 L-shaped coupling ground external - white, BE0021311 L-shaped coupling ground internal - white, BE0021401 Flexible coupling - white, BE0022001 Cover - length 1000 mm - white, BE0030011 Lighting track 3-CCT aluminium 1000 mm - black, BE0030021 Lighting track 3-CCT aluminium 2000 mm - black, BE0030031 Lighting track 3-CCT aluminium 3000 mm - black, BE0031001 Supply connector earth conductor on left - black, BE0031011 Supply connector earth conductor on right - black, BE0031101 Concealed coupling with wiring - black, BE0031201 End cap - black, BE0031301 L-shaped coupling ground external - black, BE0031311 L-shaped coupling ground internal - black, BE0031401 Flexible coupling - black, BE0032001 Cover - length 1000 mm - black, BE0036101 3-phase recessed monopoint - black, BE0036111 3-phase ceiling monopoint - black, WB0401B Standard snoot - white, WB0401N Standard snoot - black, WB0402B Asymmetrical snoot - white, WB0402N Asymmetrical snoot - black, WB0403N Barn doors - black, WH0710 Honeycomb louvre tested and approved via E.O.L. (End Of Line) test with functioning test and check of electrical power consumption Copied

Mounting	on horizontal track
Number and type of LED	1 COB LED Citizen (3 MacAdam steps), 3-step MacAdam, 50 000h L90 B10 (Ta 25°C)
LED colour	2700K, 3000K, 4000K
Optics	14°, 29°
CRI Colour Rendering Index	94
Body material	body in anodized aluminium
Finishes	black, white
Power supply unit	built-in power supply unit
Ingress protection	IP40
Status	Product being discontinued

Read more

Close

Download

See all downloads

Gallery

Accessories and power supply units

Accessories (31)

Honeycomb louvre

Order together with the lighting fixture

WH0710

Honeycomb louvre

built into the lighting fixture

Snoots

WB0401B Standard snoot - white	WB0401N Standard snoot - black
WB0402B Asymmetrical snoot - white	WB0402N Asymmetrical snoot - black

Barn doors

WB0403N

Barn doors - black

Track accessories

BE0017001 Suspension kit with 2 m cable and clutch adjustment	BE0020011 Lighting track 3-CCT aluminium 1000 mm - white
BE0020021 Lighting track 3-CCT aluminium 2000 mm - white	BE0020031 Lighting track 3-CCT aluminium 3000 mm - white
BE0021001 Supply connector earth conductor on left - white	BE0021011 Supply connector earth conductor on right - white
BE0021101 Concealed coupling with wiring - white	BE0021201 End cap - white
BE0021301 L-shaped coupling ground external - white	BE0021311 L-shaped coupling ground internal - white
BE0021401 Flexible coupling - white	BE0022001 Cover - length 1000 mm - white
BE0030011 Lighting track 3-CCT aluminium 1000 mm - black	BE0030021 Lighting track 3-CCT aluminium 2000 mm - black
BE0030031 Lighting track 3-CCT aluminium 3000 mm - black	BE0031001 Supply connector earth conductor on left - black
BE0031011 Supply connector earth conductor on right - black	BE0031101 Concealed coupling with wiring - black
BE0031201 End cap - black	BE0031301 L-shaped coupling ground external - black
BE0031311 L-shaped coupling ground internal - black	BE0031401 Flexible coupling - black
BE0032001 Cover - length 1000 mm - black	BE0036101 3-phase recessed monopoint - black
BE0036111 3-phase ceiling monopoint - black
