Colorado 8.2

Linear profiles for outdoor applications

linear profile for outdoor applications - 85W 230Vac - 1232 mm - Tunable White - DMX512+RDM

Generate code

Customize this product

This product can be customized, thanks to our flexible in-house production. We suggest some of the possible customized versions on the right, but if you have any different requirements, we can review them together.

Possible customizations:

Lenght 335 mm, class III, 48Vdc

Technical data

Print technical data

kg 1500 - kN 15
10,6 kg
IP65
IP67
IP69
IK10
DMX+RDM

Installation	linear profile for outdoor applications
Power consumption	85W
Power supply	230Vac
Lumen output at source	10697 lm (3500K)
Delivered lumen output	7691 lm (3500K, 16°)
Datasheet	Colorado 8.2 linear profile for outdoor applications; drive-over up to 1500 kg; recessed (floor); Power consumption: 85W; Power supply: 230Vac; Lumen output at source: 10697 lm (3500K); Delivered lumen output: 7691 lm (3500K, 16°); 24 power LEDs pitch 50 mm, 60 000h L80 B10 (Ta 25°C); LED colour: Tunable White: 2200K — 5000K; Optics: 16° tiltable ±20°, 26° tiltable ±20°, 36° tiltable ±20°: optical system composed of a series of equidistant tiltable light sources, 50 mm apart. Fitted with locking screw. The deep-set PMMA TIR lens guarantees high-quality light emission and visual comfort, 16°x66° tiltable ±20°: optical system composed of a series of equidistant tiltable light sources, 50 mm apart. Fitted with locking screw. The deep-set elliptical PMMA TIR lens guarantees high-quality light emission and visual comfort, diffuse tiltable ±20°: optical system composed of a series of adjustable light sources. Fitted with locking screw. The PMMA TIR lens guarantees high-quality light emission and visual comfort; CRI Colour Rendering Index: 80; Body material: body made of Anticorodal® low-copper-content aluminium EN AW 6060 T5 for excellent heat dissipation, manufactured from an extruded profile and subjected to a deep black electro-colouring process (between 10 and 15 microns) for excellent corrosion resistance. Caps made of technopolymer for greater resistance to corrosion and atmospheric agents; Screen material: 10-mm-thick acid-etched, tempered extra-clear glass, with grey-vitrified serigraphy (RAL 7015) resistant to knocks and scratches, and with high transmittance to eliminate chromatic aberrations. (diffuse version), 10-mm-thick transparent, tempered extra-clear glass, high-transmittance with grey-vitrified serigraphy (RAL 7015), to ensure chromatic uniformity and excellent resistance to knocks and scratches (optics version); Seals: Black peroxide EPDM O-rings guarantee lasting resistance to UV rays; Installation: DMX+RDM version: IP68 five-pin female connector for the power supply, and IP68 four-pin female connector for the DMX+RDM signal; built-in power supply unit; Control system: DMX512+RDM; Ingress protection: IP65, IP67, IP69; Impact resistance: IK10; In/out connection and easy wiring with quick connectors designed to connect the profiles one after the other; Casambi-compatible version, controllable with the Casambi app, available on request; Operating temperature: -20°C — +45°C; Maximum device temperature: 40°C (Ta 25°C); Glow wire test: 650°; Photobiological safety: in accordance with IEC TR 62778:2014; Appliance class: class II; Weight: 10600 g; Dimensions: 1232x94x118 mm; Energy efficiency class: F (light source) in accordance with EU 2019/2015; Accessories: WCCA22A0F Outer casing, WFA0001 1.5-m 3-pin interconnect cable, WFA01 4-pin male connector, WFA0105 5-m 3-pin interconnect cable, WFA0201 1.5-m 5-pin interconnect cable, WFA0205 5-m 5-pin interconnect cable, WFA05 5-pin male connector; tested and approved via E.O.L. (End Of Line) test with functioning test and check of electrical power consumptionColorado 8.2 linear profile for outdoor applications drive-over up to 1500 kg recessed (floor) Power consumption: 85W Power supply: 230Vac Lumen output at source: 10697 lm (3500K) Delivered lumen output: 7691 lm (3500K, 16°) 24 power LEDs pitch 50 mm, 60 000h L80 B10 (Ta 25°C) LED colour: Tunable White: 2200K — 5000K Optics: 16° tiltable ±20°, 26° tiltable ±20°, 36° tiltable ±20°: optical system composed of a series of equidistant tiltable light sources, 50 mm apart. Fitted with locking screw. The deep-set PMMA TIR lens guarantees high-quality light emission and visual comfort, 16°x66° tiltable ±20°: optical system composed of a series of equidistant tiltable light sources, 50 mm apart. Fitted with locking screw. The deep-set elliptical PMMA TIR lens guarantees high-quality light emission and visual comfort, diffuse tiltable ±20°: optical system composed of a series of adjustable light sources. Fitted with locking screw. The PMMA TIR lens guarantees high-quality light emission and visual comfort CRI Colour Rendering Index: 80 Body material: body made of Anticorodal® low-copper-content aluminium EN AW 6060 T5 for excellent heat dissipation, manufactured from an extruded profile and subjected to a deep black electro-colouring process (between 10 and 15 microns) for excellent corrosion resistance. Caps made of technopolymer for greater resistance to corrosion and atmospheric agents Screen material: 10-mm-thick acid-etched, tempered extra-clear glass, with grey-vitrified serigraphy (RAL 7015) resistant to knocks and scratches, and with high transmittance to eliminate chromatic aberrations. (diffuse version), 10-mm-thick transparent, tempered extra-clear glass, high-transmittance with grey-vitrified serigraphy (RAL 7015), to ensure chromatic uniformity and excellent resistance to knocks and scratches (optics version) Seals: Black peroxide EPDM O-rings guarantee lasting resistance to UV rays Installation: DMX+RDM version: IP68 five-pin female connector for the power supply, and IP68 four-pin female connector for the DMX+RDM signal built-in power supply unit Control system: DMX512+RDM Ingress protection: IP65, IP67, IP69 Impact resistance: IK10 In/out connection and easy wiring with quick connectors designed to connect the profiles one after the other Casambi-compatible version, controllable with the Casambi app, available on request Operating temperature: -20°C — +45°C Maximum device temperature: 40°C (Ta 25°C) Glow wire test: 650° Photobiological safety: in accordance with IEC TR 62778:2014 Appliance class: class II Weight: 10600 g Dimensions: 1232x94x118 mm Energy efficiency class: F (light source) in accordance with EU 2019/2015 Accessories: WCCA22A0F Outer casing, WFA0001 1.5-m 3-pin interconnect cable, WFA01 4-pin male connector, WFA0105 5-m 3-pin interconnect cable, WFA0201 1.5-m 5-pin interconnect cable, WFA0205 5-m 5-pin interconnect cable, WFA05 5-pin male connector tested and approved via E.O.L. (End Of Line) test with functioning test and check of electrical power consumption Copied

Mounting	recessed (floor)
Number and type of LED	24 power LEDs pitch 50 mm, 60 000h L80 B10 (Ta 25°C)
LED colour	Tunable White: 2200K — 5000K
Optics	16° tiltable ±20°, 26° tiltable ±20°, 36° tiltable ±20°, 16°x66° tiltable ±20°, diffuse tiltable ±20°
CRI Colour Rendering Index	80
Body material	body in black-anodized anticorodal aluminium, caps in technopolymer
Screen material	screen in grey-serigraphed, acid-etched, tempered extra-clear glass (diffuse version), screen in serigraphed-grey and transparent, tempered extra-clear glass (optics version)
Power supply unit	built-in power supply unit
Control system	DMX512+RDM
Ingress protection	IP65, IP67, IP69
Impact resistance	IK10
Features	In/out connection and easy wiring with quick connectors designed to connect the profiles one after the other
Notes	Casambi-compatible version, controllable with the Casambi app, available on request
Status	Available

Read more

Close

Download

See all downloads

Gallery

Accessories and power supply units

Accessories (7)

Outer casings

WCCA22A0F

Outer casing

Wiring materials

WFA0001 1.5-m 3-pin interconnect cable for the DMX signal	WFA01 4-pin male connector for in/out connection IP68
WFA0105 5-m 3-pin interconnect cable for the DMX signal	WFA0201 1.5-m 5-pin interconnect cable
WFA0205 5-m 5-pin interconnect cable	WFA05 5-pin male connector for in/out connection IP68

Power supply units (0)

No power supply units

Control gear (0)

No controllers

Control input (1)

DMX01

DMX Controller

Input	230Vac
Output	DMX512 bus
Dimensions	79x92x43 mm, 120 g
