Geko 6.0

Wall mounted for outdoor applications

wall mounted for outdoor applications - diffuse optic, double beams - 16W / 28W 230Vac - 100x170x100 mm

Customize this product

This product can be customized, thanks to our flexible in-house production. We suggest some of the possible customized versions on the right, but if you have any different requirements, we can review them together.

Possible customizations:

Built-in DALI control
Remote emergency light

Technical data

Print technical data

Updated to GK60115DT

kg 2,20
IP65
IK07

Installation	wall mounted for outdoor applications, double beam
Power consumption	28W
Power supply	230Vac
Lumen output at source	2240 lm (3000K, 28W)
Delivered lumen output	1662 lm (3000K, 28W)
Datasheet	Geko 6.0 code: GK60115DT wall mounted for outdoor applications, double beam; surface mounted (wall); Power consumption: 28W; Power supply: 230Vac; Lumen output at source: 2240 lm (3000K, 28W); Delivered lumen output: 1662 lm (3000K, 28W); power LED matrix, 3-step MacAdam, 50 000h L80 B10 (Ta 25°C); LED colour: 3000K; Optics: diffuse; CRI Colour Rendering Index: 80; Body material: body in die-cast aluminium; Finishes: cor-ten; RAL finish on request; Screen material: screen in serigraphed, sandblasted, tempered extra-clear glass; built-in power supply unit; connection box with 0.30 m cable; Ingress protection: IP65; Impact resistance: IK07; spacer with RAL finish available on request, Casambi-compatible version, controllable with the Casambi app, available on request; Operating temperature: -20°C — +45°C; Glow wire test: 960°; Photobiological safety: photobiological safety: risk group 1 according to EN 62471:2006; Appliance class: class I; Weight: 2200 g; Dimensions: 170x100x100 mm; Energy efficiency class: F (light source) in accordance with EU 2019/2015; Accessories: WD0300T Spacer - cor-ten; tested and approved via E.O.L. (End Of Line) test with functioning test and check of electrical power consumptionGeko 6.0 code: GK60115DT wall mounted for outdoor applications, double beam surface mounted (wall) Power consumption: 28W Power supply: 230Vac Lumen output at source: 2240 lm (3000K, 28W) Delivered lumen output: 1662 lm (3000K, 28W) power LED matrix, 3-step MacAdam, 50 000h L80 B10 (Ta 25°C) LED colour: 3000K Optics: diffuse CRI Colour Rendering Index: 80 Body material: body in die-cast aluminium Finishes: cor-ten RAL finish on request Screen material: screen in serigraphed, sandblasted, tempered extra-clear glass built-in power supply unit connection box with 0.30 m cable Ingress protection: IP65 Impact resistance: IK07 spacer with RAL finish available on request, Casambi-compatible version, controllable with the Casambi app, available on request Operating temperature: -20°C — +45°C Glow wire test: 960° Photobiological safety: photobiological safety: risk group 1 according to EN 62471:2006 Appliance class: class I Weight: 2200 g Dimensions: 170x100x100 mm Energy efficiency class: F (light source) in accordance with EU 2019/2015 Accessories: WD0300T Spacer - cor-ten tested and approved via E.O.L. (End Of Line) test with functioning test and check of electrical power consumption Copied

Mounting	surface mounted (wall)
Number and type of LED	power LED matrix, 3-step MacAdam, 50 000h L80 B10 (Ta 25°C)
LED colour	3000K
Optics	diffuse
CRI Colour Rendering Index	80
Body material	body in die-cast aluminium
Screen material	screen in serigraphed, sandblasted, tempered extra-clear glass
Finishes	cor-ten
Power supply unit	built-in power supply unit
Power cables	connection box with 0.30 m cable
Ingress protection	IP65
Impact resistance	IK07
Notes	spacer with RAL finish available on request, Casambi-compatible version, controllable with the Casambi app, available on request
Status	Available

Read more

Close

Download

See all downloads

JPG Images
PDF Catalogue
PDF Technical sheet
PDF Instruction sheet
Datasheet TXT Type
- Generic, for the product Geko 6.0
- Specific, for code GK60115DT
DXF Technical drawing
3DS File
LDT Photometric file Type
- Generic, for the product Geko 6.0
- Specific, for code GK60115DT
IES Photometric file Type
- Generic, for the product Geko 6.0
- Specific, for code GK60115DT
EU declaration of conformity

Gallery

Accessories and power supply units

Accessories (1)

Accessories for product code GK60115DT

Spacers

WD0300T

Spacer - cor-ten

Power supply units (0)

Power supply units for product code GK60115DT

No power supply units

Control gear (0)

Control gear for product code GK60115DT

No controllers

Control input (0)

No control inputs

Projects

Versions
