Echo LED 3.0

Recessed for indoor applications

recessed for indoor applications - 36W 230Vac - ø197 mm

Generate code

Technical data

Print technical data
  • CE mark for the European Union
  • UKCA mark for Great Britain
  • EAC
  • lighting fixture with LED technology
  • appliance class II
  • gross weight
    kg 1,15
  • cut-out size
    ø180 mm
  • IP40
  • F
Installation recessed downlight for indoor applications
Power consumption 36W
Power supply 230Vac
Lumen output at source 3505 lm (3000K)
Delivered lumen output 2418 lm (3000K)
Datasheet

Copied

Mounting recessed (ceiling)
Number and type of LED power LED matrix, 3-step MacAdam, 50 000h L80 B10 (Ta 25°C)
LED colour 3000K, 4000K
Optics diffuse
CRI Colour Rendering Index 80
Body material body and trim in die-cast aluminium
Screen material screen in one-side-frosted polycarbonate
Finishes white
Power supply unit power supply unit included
Power cables includes 0,30 m cable
Ingress protection IP40
Notes Casambi-compatible version, controllable with the Casambi app, available on request
Status Product being discontinued
