Quad Maxi 2.1

Recessed for indoor applications

recessed for indoor applications - 8W 230Vac - tiltable optics ±15° - 70x70 mm - trimless

Generate code

Technical data

Print technical data
Required outer casing not included
  • CE mark for the European Union
  • UKCA mark for Great Britain
  • EAC
  • ETL
    on request
  • lighting fixture with LED technology
  • appliance class II
  • gross weight
    kg 0,30
  • cut-out size
    70x70 mm
  • IP40
  • DALI
  • PUSH
  • 0/1-10V
  • RAL finish on request
  • F
Installation recessed downlight for indoor applications
Power consumption 8W
Power supply 230Vac
Lumen output at source 512 lm (3000K)
Delivered lumen output 425 lm (3000K, 29°)
Datasheet

Copied
Mounting recessed (ceiling)
Number and type of LED 1 multichip power LED, 2-step MacAdam, 50 000h L90 B10 (Ta 25°C)
LED colour 2700K, 3000K, 4000K
Optics 20° tiltable ±15°, 29° tiltable ±15°, 54° tiltable ±15°
CRI Colour Rendering Index 80
Body material body in anodized aluminium, trim in steel
Finishes white
Power supply unit power supply unit included
Power cables includes 0,30 m cable
Control system ON/OFF, PUSH, DALI, 0/1-10V
Ingress protection IP40
Notes Casambi-compatible version, controllable with the Casambi app, available on request
Status Product being discontinued
