Siri Blvd 1.0

Urban lighting

urban lighting - 38W 230Vac - pole mounted - 189x371x124 mm

Generate code

Customize this product

This product can be customized, thanks to our flexible in-house production. We suggest some of the possible customized versions on the right, but if you have any different requirements, we can review them together.

Possible customizations:

Double-beam version

Technical data

Print technical data

kg 4,60
IP66
IK06

Installation	urban lighting, projector on short arm
Power consumption	38W
Power supply	230Vac
Lumen output at source	3402 lm (3000K)
Delivered lumen output	2081 lm (3000K, footpath), 2110 lm (3000K, pedestrian zone), 2134 lm (3000K, cycle path), 2180 lm (3000K, asymmetrical)
Datasheet	Siri Blvd 1.0 urban lighting, projector on short arm; pole mounted Ø60 mm; Power consumption: 38W; Power supply: 230Vac; Lumen output at source: 3402 lm (3000K); Delivered lumen output: 2081 lm (3000K, footpath), 2110 lm (3000K, pedestrian zone), 2134 lm (3000K, cycle path), 2180 lm (3000K, asymmetrical); 4 high-intensity power LEDs, 3-step MacAdam, 50 000h L90 B10 (Ta 25°C); LED colour: 2700K, 3000K, 4000K; Optics: asymmetrical, cycle path, footpath, pedestrian zone; CRI Colour Rendering Index: 80; Body material: body in die-cast aluminium; Finishes: anthracite; RAL finish on request; Screen material: screen in serigraphed, tempered extra-clear glass; built-in power supply unit; includes 5 m neoprene cable, H05RN-F 2X1,0 Ø7,0 mm; Control system: Virtual midnight, ON/OFF; Ingress protection: IP66; Impact resistance: IK06; Max exposed surface: 0,056 m², Lateral surface: 0,021 m²; double-beam version available on request; DALI version available on request, Casambi-compatible version, controllable with the Casambi app, available on request; Protection systems: IPS (Intelligent Protection System) protects lighting fixtures from water infiltrations, which can occur if there are faulty junctions between the cables in outdoor or underwater applications. This innovation, patented by L&L, also guarantees electrical protection against polarity reversal, hot plugging, ESD and power surges, which can occur if there are faults in the electrical circuit; The PID (Protective Impedance Device) protects lighting fixtures from electrical phenomena external to the system, such as static electricity accumulation or electromagnetic interference coming from the mains power. Generally, these are events with a low energy content; The SPD (Surge Protection Device) protects lighting fixtures from electrical phenomena external to the system, such as power surges. In particular, this device is specifically for protection against serious events with a high energy content; This is an NTC thermistor mounted on the LED board to protect the lighting fixture against overheating. Should the product function at an operating temperature greater than the maximum temperature at which it can operate correctly, the protection is activated and gradually reduces the power. The NTC causes the integrated electronic parts to cool down to avoid the lighting fixture instantly switching itself off. When the operating temperature is again within normal range, the NTC automatically restores the lighting fixture’s original operating conditions; Operating temperature: -20°C — +45°C; Glow wire test: 960°; Photobiological safety: photobiological safety: risk group 1 according to EN 62471:2006; Appliance class: class II; Weight: 4600 g; Dimensions: 189x371x124 mm; Energy efficiency class: F (light source) in accordance with EU 2019/2015; tested and approved via E.O.L. (End Of Line) test with functioning test and check of electrical power consumptionSiri Blvd 1.0 urban lighting, projector on short arm pole mounted Ø60 mm Power consumption: 38W Power supply: 230Vac Lumen output at source: 3402 lm (3000K) Delivered lumen output: 2081 lm (3000K, footpath), 2110 lm (3000K, pedestrian zone), 2134 lm (3000K, cycle path), 2180 lm (3000K, asymmetrical) 4 high-intensity power LEDs, 3-step MacAdam, 50 000h L90 B10 (Ta 25°C) LED colour: 2700K, 3000K, 4000K Optics: asymmetrical, cycle path, footpath, pedestrian zone CRI Colour Rendering Index: 80 Body material: body in die-cast aluminium Finishes: anthracite RAL finish on request Screen material: screen in serigraphed, tempered extra-clear glass built-in power supply unit includes 5 m neoprene cable, H05RN-F 2X1,0 Ø7,0 mm Control system: Virtual midnight, ON/OFF Ingress protection: IP66 Impact resistance: IK06 Max exposed surface: 0,056 m², Lateral surface: 0,021 m² double-beam version available on request; DALI version available on request, Casambi-compatible version, controllable with the Casambi app, available on request Protection systems: IPS (Intelligent Protection System) protects lighting fixtures from water infiltrations, which can occur if there are faulty junctions between the cables in outdoor or underwater applications. This innovation, patented by L&L, also guarantees electrical protection against polarity reversal, hot plugging, ESD and power surges, which can occur if there are faults in the electrical circuit; The PID (Protective Impedance Device) protects lighting fixtures from electrical phenomena external to the system, such as static electricity accumulation or electromagnetic interference coming from the mains power. Generally, these are events with a low energy content; The SPD (Surge Protection Device) protects lighting fixtures from electrical phenomena external to the system, such as power surges. In particular, this device is specifically for protection against serious events with a high energy content; This is an NTC thermistor mounted on the LED board to protect the lighting fixture against overheating. Should the product function at an operating temperature greater than the maximum temperature at which it can operate correctly, the protection is activated and gradually reduces the power. The NTC causes the integrated electronic parts to cool down to avoid the lighting fixture instantly switching itself off. When the operating temperature is again within normal range, the NTC automatically restores the lighting fixture’s original operating conditions Operating temperature: -20°C — +45°C Glow wire test: 960° Photobiological safety: photobiological safety: risk group 1 according to EN 62471:2006 Appliance class: class II Weight: 4600 g Dimensions: 189x371x124 mm Energy efficiency class: F (light source) in accordance with EU 2019/2015 tested and approved via E.O.L. (End Of Line) test with functioning test and check of electrical power consumption Copied

Mounting	pole mounted Ø60 mm
Number and type of LED	4 high-intensity power LEDs, 3-step MacAdam, 50 000h L90 B10 (Ta 25°C)
LED colour	2700K, 3000K, 4000K
Optics	asymmetrical, cycle path, footpath, pedestrian zone
CRI Colour Rendering Index	80
Body material	body in die-cast aluminium
Screen material	screen in serigraphed, tempered extra-clear glass
Finishes	anthracite
Power supply unit	built-in power supply unit
Power cables	includes 5 m neoprene cable, H05RN-F 2X1,0 Ø7,0 mm
Control system	Virtual midnight, ON/OFF
Ingress protection	IP66
Impact resistance	IK06
Features	Max exposed surface: 0,056 m², Lateral surface: 0,021 m²
Notes	double-beam version available on request; DALI version available on request, Casambi-compatible version, controllable with the Casambi app, available on request
Status	Available
